HOME >> A2F/k SERIES OF BENT AXIS AXIAL PLUNGER CONSTANT PUMP/MOTOR¡¡¡¡¡¡¡¡¡¡ >> Parameter and principle

A2F series of bent axis constant pump/motor are advanced hydraulic components at home and abroad. They can interchange completely with the overseas products, which have the same type and same specification, A2F series of bent axis constant pump/motor are reversible components; They can meet needs of all kinds of hydraulic systems by installing different valve plate and back plate. So they can be widely used in: metallurgical, mine, petroleum, architecture, engineering machinery, railways, shipping shipbuilding, plastics processing, light industry, machine tools, machinery open, closed hydraulic system.

A2F/K-107
A2F/K-45--A2F/K-55
A2F/K-28

A2F/K-23
A2F/K-10¡¢12
A2F/K-6

Specification
Geometric
Capacity cm3/r
Maximum Rotational
Speed r/min
Pressure MPa
Input Power(KW) n=1450r/min
P=PN
Output Power
Nm P=PN
Mass kg
Closed
nmax
Open
nmaxOpen
Rated
PN
Maximun
Pmax
A2F/K-6
6.2
6000
4000
35
40
5.1
33.9
5
A2F/K-10
9.4
6000
4000
35
40
7.8
51.4
5
A2F/K-12
11.6
6000
4000
35
40
9.6
63.4
5
A2F/K-23
22.7
4750
3000
35
40
18.8
124
12
A2F/K-28
28.1
4750
3000
35
40
23.3
154
12
A2F/K-45
44.3
3750
2500
35
40
36.7
242
23
A2F/K-55
54.8
3750
2500
35
40
45.4
299
23
